Quarry Mining Hydraulic Impact Crusher Limestone Gravel Feeding Material

Impact Crusher Specifications:

Impact Crusher Brief Description:

1. Name: impact crusher

2. Model: PFC-1420

3. Quality: national quality control standards

4. Certification: CE/ ISO9001:2008

Impact Crusher Introduction:

This impact crusher has 45 degree feed chute with replaceable liners. The main frame can be opened by hydraulic device. Thick blow bars with locking tongue set into a replaceable backing bar seat. All curtain liners are interchangeable. Positive rotor locks to ensure the safety of persons who change the rotor. With the strengthening and toughening bear and replaceable backing bar seat, this crusher can be applied to the waste recycling materials processing. Final products are in a good product shape, the low proportion of conifer-like.

Impact Crusher Working Principle:

This impact crusher machine crushes materials with impact force. When the materials enter the blow bar area, they are crushed due to the high-speed impact of the blow bar and are thrown to the impact plates on the rotor for secondary crush. Then the materials will be shot back to the blow bar again for the third crush. This process repeats until the materials are crushed to the required size and discharged from the lower part of the machine. The size and shape of the finished powder can be changed by adjusting the gap between the impact rack and rotor support. The machine employs self-weigh security device in its back frame. When other objects enter the impact cavity, they will be forced out of the machine by the impact rack in the front and back of the machine.

Impact Crusher Advantages and Characteristics:

1. Hydraulic curtain cleaning
2. Hydraulic fully
3. Hydraulic opening device
4. Hydraulic adjusting discharge

Impact Crusher Guarantee And After-sales Service:

1. Two years guarantee for main machine, excluding wearing parts

2. Experienced technicians guidance is available

3. 24 hours technical support by e-mail, by phone.

4. Use-friendly English user manual

5. Engineers could be dispatched to the quarry site, if requested by customer.

Impact Crusher Applications:

This PFC hydraulic Impact crusher are designed for crushing ores and rocks with particle sizes less than 120-350mm and compression strength no more than 350MPa.It is suitable for crushing different compression strength of rocks in mining, cement and concrete industries, and is widely used to produce fine stones for constructions of highway, airport, building, etc.
